GI Junction Boxes, Sheet Metal Components, Manufacturer, Pune, India

Range & Specifications
Code No.	Inside Dimensions (mm) H x W x D	Applications
Side Hinged – Door fixed to base with hinges
GS-JB-1414	140 x 140 x 95	Junction box/cut-out box/fuse box for single phase/2 core low wattage FTL/CFL based lighting system for pedestrian/pathway illumination.
GS-JB-2014	200 x 140 x 95	Pole mounted junction box/cut-out box/fuse box for road/street lighting for 3 phase/4 core high wattage HPSV/HPMV/MH based lighting system for industrial applications.
GS-JB-2817	240 x 130 x 110
GS-JB-2520	250 x 200 x 105
GS-JB-3020[1] (right hinged)	300 x 200 x 105
Top Hinged – Door fixed to base with hinges on top
GS-JB-1616-T	140 x 140 x 100	Junction box/cut-out box/fuse box for single phase/2 core low wattage FTI/CFL based lighting system for pedestrian/pathway illumination..
GS-JB-3016-T	275 x 135 x 110	Pole mounted junction box/cut-out box/fuse box for road/street lighting for 3 phase/4 core high wattage HPSV/HPMV/MH based lighting system for industrial, commercial as well as flood lighting applications.
Sliding – Door fixed to base by means of sliding
CCV-400-01	340 x 160 x 90	Pole mounted junction box/cut-out box/fuse box for road/street lighting for 3 phase/4 core high wattage HPSV/HPMV/MH based lighting system for industrial, commercial as well as flood lighting applications. Provision for fixing 2 cut-outs, one for lighting and other for kiosks/signage/emergency power supply.
Removable – Door fixed to the base by means of hardware
GS-JB-1510-R	55 x 100 x 60	Control terminal box/cut-out box
GS-JB-1816-R	185 x 165 x 60
GS-JB-2818-R	280 x 180 x 60

Cable Trays Manufacturer

GI Junction Box, GI Junction Boxes, Manufacturer, Supplier, Exporter, Pune, Maharashtra, India, Japan, Bahrain, Iraq, Kuwait, Nigeria, Ethiopia, Egypt, South Africa, Afghanistan, Azerbaijan, Tajikistan, United Arab Emirates, Israel

GI (Galvanized Iron) Junction Boxes (Sheet Metal Components)
